Kubernetes Application Deployment with Helm - A beginner Guide!
3 likes2,531 views
The document covers Kubernetes application deployment methods, focusing on Helm as a package manager that facilitates managing Kubernetes applications. It outlines various deployment strategies and introduces Helm 3, highlighting its significant updates such as the removal of the Tiller component, enhancements with library charts, and plans for migration from Helm 2. The content also includes a demo of deploying applications using Helm on Google Kubernetes Engine (GKE).
Kubernetes Application Deployment with Helm - A beginner Guide!
- 1. Krishna Kumar, CNCF Ambassador @krish_00 September 2019, Infosys Campus Bangalore Application Deployment in Kubernetes with
- 2. Outline K8s App Deployment Methods! Helm & Charts .... Demo – helm in GKE*
- 3. What’s in Kubernetes ? Kubernetes: Container Orchestration Engine – abstracts underlying resources to deploy workloads Micro Services: A fully functional software feature independently accessed as a service Docker: Package applications in containers CNCF: Cloud Native Computing Foundation: https://cncf.io Kubenetes – helmsman(pilot);
- 4. K8s Application Deployment File kubectl apply -f deployment.yaml <deployment.yaml> apiVersion: apps/v1 kind: Deployment metadata: name: nginx-deployment labels: app: nginx spec: replicas: 3 selector: matchLabels: app: nginx template: metadata: labels: app: nginx spec: containers: - name: nginx image: nginx:1.7.9 ports: - containerPort: 80 nginx – application for load balancer 3 pods will be created; one for each replica map of {key,value} pairs indicates that the Pods run one container nginx Docker Hub image at version 1.7.9 Application Service port: 80
- 5. Application Deployment methods blue/green: New version alongside old version then switching at one point; Rollout/Rollback canary: Release a new version to few users and then decide full rollout based on result a/b testing: Feature testing based on statistics; dark deployment that users are unaware of update rolling: Update new version one after another slowly with no downtime recreate: Create a new one and kill the old one; best for development environments shadow: Both versions are running parallel with not impacting other; mocking services & dependecies like ...... types: Stateless, Statefull, Affinity/Antiaffinity, Declarative/Imperative clusters: Multi Cluster, Hybrid Cloud, Multi Cloud mechanics: Manual, Batch, Package Manager, CI/CD
- 6. DevOps Pipeline DevOps helps: infrastructure as code continuous integration continuous deployment automated release And do: • Setup in k8s Clusters – Jenkin, Dev & Prod • Production environment with Loadbalancer • Create two namesapces - production & canary • Create jenkin job, build & push to Registry ● Deploy Canary release (dev, prod, etc.) ● And production release ● And more.... https://cloud.google.com/solutions/continuous-delivery-jenkins-kubernetes-engine
- 7. K8s Application Deployment/Automation Tools... Kubectl – Create, manage and deploy k8s artifacts - https://kubernetes.io/docs/reference/kubectl/ Kustomize - A template-free way to customize application configuration - https://kustomize.io/ CNAB - Cloud Native Application Bundling - https://cnab.io/ Skaffold - building, pushing and deploying your application - https://skaffold.dev/ Spinnakar – Multi cloud continous delivery - https://www.spinnaker.io/ Kudo - Universal declarative Operator - https://kudo.dev Kompose – Move docker file to k8s objects - http://kompose.io/ Draft – Streamlined k8s Deployment - https://draft.sh/ Brigade – Event driven scripting for k8s - https://brigade.sh/ Kashti – Visualization Dashboard for Brigade - https://github.com/brigadecore/kashti Jenkin - k8s plugin & Jenkin X - https://github.com/jenkinsci/kubernetes-plugin Github - Marketplace for tools - https://github.com/marketplace/category/continuous-integration Helm – The package manager for k8s - https://helm.sh/
- 8. What is Helm? Helm is a package manager, helps you manage Kubernetes applications — define, install, and upgrade even the most complex Kubernetes application. Helm is like apt or yum in linux world Why do we need a package manager ● Application focused Better control ● Container version handling - upgrade/rollback ● Manage dependencies ● Reproducible and shareable Helm initially started with Deis (now with Microsoft) & then Google Deployment Manger team joined to create helm2. Helm is now in CNCF Incubation project - https://helm.sh/ Helm - wheel
- 9. Charts Chart - Charts are curated application definitions for Helm. A chart is organized as a collection of files inside of a directory - that is package. Charts are placed in repository similar to Docker Registry, Quay, etc. ● Helm’s own Chart Museum - https://chartmuseum.com/ ● CNCF Project Harbor - https://goharbor.io/ ● Gihub charts - https://github.com/helm/charts ● Helm Hub: Charts hosted in many distributed repositories - https://hub.helm.sh/ Helm manages charts, versions and releases Instance of application - Helm Release
- 10. Sample Chart /<projectName> - Name of the chart ● chart.yaml – Information about chart ● values.yaml – default configuration values ● LICENSE – license for the chart ● README.md – human readable text ● requirements.yaml – dependencies for the chart ● requirements.lock – lock the same version in requiremnts ● /charts/ - dependencies chart upon which this chart depends ● /templates/ - files in go template language https://github.com/helm/charts helm install stable/nginx-ingress --> will install nginx in k8s cluster
- 11. Helm Releases v2 (v2.14.3) Released in 2016 (Currently production/maintenance) A server in-cluster component was called Tiller, and it handled installing and managing Helm charts. In Helm 2, install created v1, a subsequent upgrade created v2, and so on. In Tiller name space you can store only one instanace name Later Kubernetes introduced RBAC & CRDs. With RBAC, locking down Tiller in production becomes difficult; so start providing permissive default configuration that creted nightmare for DevOps & SREs. So had to move Tiller, instead could simply fetch information from the Kubernetes API server, render the Charts client-side, and store a record of the installation in Kubernetes. With no Tiller, Helm’s permissions are evaluated using your kubeconfig file
- 12. Helm Releases v3 (v3.0.0-beta.3) The server side component Tiller removed Avoid Security risks Avoid installation complications Installation directly runs on the client No Service account; use existing client accoutns Namespaces are more important and release is tagged to that. One can install multiple instances name each for each namespace with same name. Releases are stored as secrets in the namespace All of the Helm 2 flags still lworks Lua templates are going to be introduced alongside Go templates (some points in future). Introduced Library charts - simply define templates for your other Helm charts to use. Store common information about your applications, without needing to replicate it across multiple Helm charts. Library chart declare in Chart.yaml as dependencies.
- 13. Helm Releases v3 .. more..... As part of the Design Proposal (some are alredy in helm3) ● Tiller is gone, and there is only one functional component (helm) ● Charts are updated with libraries, schematized values, and the ext directory ● Helm will use a "lifecycle events" emitter/handler model. ● Helm has an embedded Lua engine for scripting some event handlers. Scripts are stored in charts. ● State is maintained with two types of object: Release and a release version Secret ● Resources created by hooks will now be managed ● For pull-based DevOps workflow, a new Helm Controller project will be started ● Cross platform plugins in Lua that only have a runtime dependency on Helm ● A complementary command to helm fetch to push packages to a repository More Design details here: https://github.com/helm/community/tree/master/helm-v3
- 14. Migrate from Helm v2 to v3 Helm v3 introduces quite a lot of changes. Both Helm can coexist in the system at present. helm-2to3 plugin will allow us to migrate Helm v2 configuration and releases to Helm v3 (installed k8s objects will not be touched) Migrate everything in place to helm 3 --delete-v2-releases : will delete the helm2 release --tiller-out-cluster: Tiller is not running in the cluster In Chart v3 few changes are in place: requirements.yaml moved to Charts.yaml requirements.lock moved to Charts.lock
- 15. Helm & Operators together.. ● Build Operator with Helm chart using Operator SDK ● Helm is glorified templating tool. ● Helm Templatization by values.yaml file & Orchestration via Hooks ● Same helm for deploying applications (manifests) & control planes (operator) ● Operator is kubernative objects - Custom Resource/API + Custom Controller ● Helm chart config through value.yaml or configMap. ● Add vaidation rule in CRD Yaml file ● Register CRDs using Helm charts instead of Operator Go code. ● Add annotations to enable CR discovery & binding ● More - ● https://static.sched.com/hosted_files/helmsummit2019/ac/Operators-and-Helm-It-takes-two-to-tan go.pdf ● https://docs.okd.io/latest/operators/osdk-helm.html
- 16. DEMO Helm in GKE (Google Kubernetes Engine)
- 17. In Demo, we have gone through... 1)Created GKE cluster 2)Installed helm 2 & helm3 3)Deployed app using helm2 & helm3 4)Installed Plugin hel2to3 5)Migrated app from helm2 to helm3 6)Created a new application, build & deploy using helm3 7)Modifed the application, build & deploy using helm3 8)Added a library chart & schema validation 9)Added a Operators to the chart & also upgrade 10)Run kubectl, docker, gcloud commands to see the status at various stages
- 18. Summary ✔ k8s Application deployment methods ✔ Helm helps manage Kubernetes applications ✔ New release Helm3 Beta is now available with major chnages ✔ Library charts, Lua templates & Schema validation are new features in helm3 ✔ helm2 is in production / currently used ✔ Migration to Helm 3 from version 2 is available as a plugin. ✔ Operators and Helm can co-exists.
- 19. More about Helm ...... CNCF SIG Helm - https://www.cncf.io/announcement/2019/09/12/cloud-native-computing-foundation-announces-application-d elivery-sig/ Just finished Helm Summit on Sept 11-12 at Amsterdam - https://events.linuxfoundation.org/events/helm-summit-2019/program/schedule/ Next KubeCon on November 18-21 at San Diego https://events.linuxfoundation.org/events/kubecon-cloudnativecon-north-america-2019/schedule/ Helm https://helm.sh Thank You...
