JOURNAL OF FRUIT AND ORNAMENTAL PLANT RESEARCH
DETERMINATION OF
PHENOLIC COMPOUNDS
IN APPLES AND
PROCESSED APPLE
PRODUCTS
MSc Part I
Seat No : 14027
INTRODUCTION
 Fruits and vegetables are the major source of
phenolic compounds in diet.
 Dietary intake of phenolics is estimated 1gram/day.
 Many different phenolic compounds have been
identified in apples . The two main subtypes include
:
1. Flavonoids (quercetins glycosides and catechin
and epicatechin).
2. Phenolic Compounds (caffeic acid and p-coumaric
acid).
3. Dihydrochalcones are also present.
Quercetins glycosides are present in
the skin of apple.
Dihydrochalcones are present in the
core and seeds of apple.
Phenolic acids are present in the
cortex of apple.
MATERIAL AND METHOD
MATERIAL :
 Phenolics content was measured in four cultivars of
apple : ‘Jonagold’ , ‘Sampion’ , ‘Idared’ and ‘Topaz’.
 Replicate batches of these cultivars were
processed into clear juice, cloudy juice and
applesauce by industrial procedures.
 Clear apple juices were digested with Panzym MK
at 50°C or Rohapect MA Plus at 20°C and ascorbic
acid was added to the cloud juice.
METHOD:
HPLC method was used to separate and quantify
phenolic compounds in apples and processed apple
products.
 The apples were divided into octants and were frozen
to -25°C and then grounded up.
o 10g of grounded apples were homogenized for 1
minute with 70% methanol. The slurry was transferred
to a 50ml volumetric flask, which was then filled to the
mark with 70% methanol.
o The mixture was filtered through Whatman No. 1 filter
paper. The filtrate was stored at −18°C prior to
analysis.
 Samples of sauces and juices were filtered, diluted
and extracted with 70% methanol in an ultrasonic
bath for 10 minutes before injection.
o All the samples before HPLC were diluted 1:3 (v/v)
with sodium acetate buffer (Solvent A)
HPLC
 HPLC was carried out using an Agilent 1100 Series
HPLC System equipped with a DAD detector.
 Phenolic compounds were separated using a
Phenomenex Fusion RP column with a guard
column.
 The mobile phase used consisted of 10.2% acetic
acid in 2mM of sodium acetate (solvent A) and
Acetonitrite (solvent B).
 The flow rate was kept constant at 0.5 ml/min for a
total run time of 72 min at 25°C.
 The system was run with a gradient pattern.
 The injection volume of the sample was 20 μl.
RESULT
 The concentration of phenolic compounds in the
cultivars evaluated was 857 mg/kg.
 The concentration of different groups of phenolic
compounds varied widely from cultivar to cultivar.
 The cultivar with the highest level of flavonols was
‘Sampion’ (477 mg/kg).
 The cultivar with the highest level of phenolic acids
was ‘Idared’.
 The cultivar with highest level of quercetin
glycosides were ‘Jonagold’ and ‘Topaz’.
 During the production of applesauce, phenolics
content did not essentially change.
 During the production of cloudy juices, phenolics
content dropped by 47%.
 During the production of clear juices with Panzym
MK, phenolics content dropped by 65%.
 During the production of clear juices with Rohapect
MA Plus, phenolics content dropped by 81%.
CONCLUSION
 Even though the cultivars differed significantly in
terms of morphology , they all contained about the
same amount of phenolics, the most abundant of
which were flavonols.
 Apple sauces contained more phenolics than
juices.
 Natural cloudy juices contained more phenolic
compounds than clear juices.
 In the production of clear juice, phenolic
compounds were more effectively extracted when
the temperature during enzyme treatment is higher.
BIBLIOGRAPHY
 Journal Of Fruit And Ornamental Plant Research ;
Vol. 14 (Suppl. 2),2006.
 Dietary intake and availability of polyphenols, J
NUTR. 130; Saclbert A., Wilska-Jeszka J.,
Markowski J., 2000.
 Flavonoids and chlorogeneic acid levels in apple
fruit: characterization of variation, Awad M.A., De
Jagger A., Van Westing L.M; 2000.
THANK YOU

Determination of phenolic compounds

  • 1.
    JOURNAL OF FRUITAND ORNAMENTAL PLANT RESEARCH DETERMINATION OF PHENOLIC COMPOUNDS IN APPLES AND PROCESSED APPLE PRODUCTS MSc Part I Seat No : 14027
  • 2.
    INTRODUCTION  Fruits andvegetables are the major source of phenolic compounds in diet.  Dietary intake of phenolics is estimated 1gram/day.  Many different phenolic compounds have been identified in apples . The two main subtypes include : 1. Flavonoids (quercetins glycosides and catechin and epicatechin). 2. Phenolic Compounds (caffeic acid and p-coumaric acid). 3. Dihydrochalcones are also present.
  • 3.
    Quercetins glycosides arepresent in the skin of apple. Dihydrochalcones are present in the core and seeds of apple. Phenolic acids are present in the cortex of apple.
  • 4.
    MATERIAL AND METHOD MATERIAL:  Phenolics content was measured in four cultivars of apple : ‘Jonagold’ , ‘Sampion’ , ‘Idared’ and ‘Topaz’.  Replicate batches of these cultivars were processed into clear juice, cloudy juice and applesauce by industrial procedures.  Clear apple juices were digested with Panzym MK at 50°C or Rohapect MA Plus at 20°C and ascorbic acid was added to the cloud juice.
  • 5.
    METHOD: HPLC method wasused to separate and quantify phenolic compounds in apples and processed apple products.  The apples were divided into octants and were frozen to -25°C and then grounded up. o 10g of grounded apples were homogenized for 1 minute with 70% methanol. The slurry was transferred to a 50ml volumetric flask, which was then filled to the mark with 70% methanol. o The mixture was filtered through Whatman No. 1 filter paper. The filtrate was stored at −18°C prior to analysis.
  • 6.
     Samples ofsauces and juices were filtered, diluted and extracted with 70% methanol in an ultrasonic bath for 10 minutes before injection. o All the samples before HPLC were diluted 1:3 (v/v) with sodium acetate buffer (Solvent A)
  • 7.
    HPLC  HPLC wascarried out using an Agilent 1100 Series HPLC System equipped with a DAD detector.  Phenolic compounds were separated using a Phenomenex Fusion RP column with a guard column.  The mobile phase used consisted of 10.2% acetic acid in 2mM of sodium acetate (solvent A) and Acetonitrite (solvent B).  The flow rate was kept constant at 0.5 ml/min for a total run time of 72 min at 25°C.  The system was run with a gradient pattern.  The injection volume of the sample was 20 μl.
  • 10.
    RESULT  The concentrationof phenolic compounds in the cultivars evaluated was 857 mg/kg.  The concentration of different groups of phenolic compounds varied widely from cultivar to cultivar.  The cultivar with the highest level of flavonols was ‘Sampion’ (477 mg/kg).  The cultivar with the highest level of phenolic acids was ‘Idared’.  The cultivar with highest level of quercetin glycosides were ‘Jonagold’ and ‘Topaz’.
  • 11.
     During theproduction of applesauce, phenolics content did not essentially change.  During the production of cloudy juices, phenolics content dropped by 47%.  During the production of clear juices with Panzym MK, phenolics content dropped by 65%.  During the production of clear juices with Rohapect MA Plus, phenolics content dropped by 81%.
  • 19.
    CONCLUSION  Even thoughthe cultivars differed significantly in terms of morphology , they all contained about the same amount of phenolics, the most abundant of which were flavonols.  Apple sauces contained more phenolics than juices.  Natural cloudy juices contained more phenolic compounds than clear juices.  In the production of clear juice, phenolic compounds were more effectively extracted when the temperature during enzyme treatment is higher.
  • 20.
    BIBLIOGRAPHY  Journal OfFruit And Ornamental Plant Research ; Vol. 14 (Suppl. 2),2006.  Dietary intake and availability of polyphenols, J NUTR. 130; Saclbert A., Wilska-Jeszka J., Markowski J., 2000.  Flavonoids and chlorogeneic acid levels in apple fruit: characterization of variation, Awad M.A., De Jagger A., Van Westing L.M; 2000.
